FEATURES:
300L with plenty of room to transport
with no spillage.Galvanized side chute
and top grate.Hydraulically operated
center chute.Spring assisted side gate
locks the gate in place and aids in the
actuation.Sprocket and chain drive
system is completely enclosed and
sealed.Bolted Grate; Easy Cleaning
Integrated Bag Splitter.Integrated top
bag cutter on an easily removed grate
Concrete and Grout with up to 1.25"
Aggregate.Precision laser cut parts,
CNC forming and robotic welding,
Constructed of A572 Grade 50 steel.
SPECIFICATIONS:
• Screw shaft diameter: 480 mm
• Bucket internal or working width : 53"
• Max Pressure : 3500 psi
• Flow Range : 11-20 gpm
• Weight* Empty Load*: 892 Ibs
• Mixing volume: 330 L
• Water volume: 435 L
• Weight at maximum capacity : 2235 Ibs
FEATURES:
300L with plenty of room to transport
with no spillage.Galvanized side chute
and top grate.Hydraulically operated
center chute.Spring assisted side gate
locks the gate in place and aids in the
actuation.Sprocket and chain drive
system is completely enclosed and
sealed.Bolted Grate; Easy Cleaning
Integrated Bag Splitter.Integrated top
bag cutter on an easily removed grate
Concrete and Grout with up to 1.25"
Aggregate.Precision laser cut parts,
CNC forming and robotic welding,
Constructed of A572 Grade 50 steel.
SPECIFICATIONS:
• Screw shaft diameter: 480 mm
• Bucket internal or working width : 53"
• Max Pressure : 3500 psi
• Flow Range : 11-20 gpm
• Weight* Empty Load*: 892 Ibs
• Mixing volume: 330 L
• Water volume: 435 L
• Weight at maximum capacity : 2235 Ibs
